CamCube HF-CC

Specifications

Application

CamCube HF-CC is a flexible range of filter housings for cylindrical molecular filters having a maximum length of 600 mm, combined with 1 stage of particle filters (bag or compact header) and with an optional rail for particle pre-filter panels (48 or 96 mm depth). Housings are used in comfort and industrial applications.

Max temperature (°C)

60°C -70°C

Material

Aluzinc (except handles, hinges and accessories)

Installation options

Left hinged service door from factory, can be changed on site.

Comment

Molecular filter types: CamCarb XG or CamCarb CM filled with different types of adsorbents depending on application. See the relevant product catalogue page for further information.
Particle filter types: All filters shall have external dimensions 592x592 mm.
Optional first stage using 48 mm particle panel filters. 96 mm depth is possible in certain configurations.
Second stage using bag filters such as Hi-Flo with maximum pocket depth of 370 mm when combined with CamCarb XG/CM 3500 or a depth of 520 mm when combined with other cylindrical products. Alternative second stage using compact filters with 25 mm header frames such as Opakfil.
Other standard features: Adjustable feet, factory mounted pressure ports, guide for housing connection, 45 mm thermal insulation. The door is hinged on the left or right and the orientation may also be changed on site.
Other options: Lockable handles. Flange for housing connection. Stainless steel SS EN 1.4301 housing material.
Filter housing material: Aluzinc (except handles, hinges and accessories).
