Quad Pulse Package I

The dust collector Quad Pulse Package 1 is designed to handle hazardous dusts from pharmaceutical and chemical processes with smaller air volumes of 500 - 1,200 m³/h (295 – 706 cfm). The QPP 1 includes one filter cartridge which is cleaned online in four segments, one at a time, to avoid interrupting operations. The unit also includes a second H14 HEPA filter stage that serves as a safety and flame barrier towards the clean side. The dust collector QPP1 is available in two different versions, the QPP1 PX is designed to be used with an external fan down to -25 kPa, the QPP1 PXI comes with an integrated fan suppling suction pressure down to -5 kPa. Both units include a pressure shock resistent housing and a Bag-In Bag-Out safe-change system for all filter stages as well as the dust discharge.

  • 1 filter cartridge, air volume up to 1,200 m³/h (706 cfm)
  • Online pulse cleaning without interrupting operations
  • Long filter life
  • Bag-In/Bag-Out safe-change for filters and dust discharge
  • Integrated explosion protection (ATEX certified)
  • Easy installation
  • High-Vacuum applications

Video

Specifications

Application
Tabletting, filling, coating, granulating, drying, mixing, blending, packaging, central vacuum.
Installation options
As space on the production floor is limited, the dust collectors of the Quad Pulse Package Series convince with their compact and space-saving design. Thanks to the integrated explosion protection no additional equipment is needed so that this plug-and-play units can be installed indoors without any limitations. Easy access for all maintenance functions.
