CamVane 100 HC

The CamVane 100 HC vane separator/weather louvre is made of specially designed profiles that effectively capture water droplets from the air stream and function as an excellent water separator. The CamVane 100 HC consists of louvres with a heating cable. The heating cable (-HC) helps prevent snow and ice accumulation on the vanes. The CamVane 100 HC is produced in aluminium which gives good corrosion protection. The louvres are made in customer specified sizes, are easy to install and maintain low pressure drop with a low noise level.

  • Class A acc to EN 13030:2001
  • Air velocities between 1,0 to 3,0 m/s
  • Low noise level
  • Very low pressure drop
  • Weather resistant material
  • Separation efficiency up to 100 % rain
  • Heat cable decreases the risk of ice build
  • ICON24 magicad

Specifications

Application
The air intake which is very efficient as rain protection can be used in all filter installations where water, rain, or fog conditions occur. Also suitable in marine environments and coastal areas.
Installation options
Mounting flange or fastening ears to customer specifications.
Comment
Product Features:
Air velocity: 1.0 - 3.0 m / s in the duct system
When dimensioning, 1.5-2 m / s in front speed is recommended for best performance
Heating cable: 220V AC, self-regulating 20W cable
Maximum dimensions: Installation dimensions up to 2500 x 2500mm
Supplied with drainage
Installation is carried out by a qualified electrician!
When ordering in stainless steel: Outer casing: AISI316L, Profiles: Aluminum EN-AW-6060
Can be delivered powder-coated in the desired RAL colour.
